Madrid-Chamartín: Clara Campoamor Station

Madrid-Chamartín Clara Campoamor Station, Adif AV Spain building images, Spanish railway station design news

Madrid-Chamartín: Clara Campoamor Station Building

16 December 2022

Design: UNStudio, with b720 Arquitectura and engineers Esteyco

Location: 28036 Madrid, Spain

Madrid-Chamartín: Clara Campoamor railway station building
image : bucharest.studio

Visualisations by: bucharest.studio, Play-Time, b720

UNStudio, b720 Arquitectura and Esteyco’s design receives top score for Madrid-Chamartín station, among proposals submitted by the world’s leading architecture firms

Estación de Madrid-Chamartín-Clara Campoamor

15th December 2022 -Adif AV this week announced that the design proposal submitted by UNStudio, with b720 Arquitectura and engineering firm Esteyco, has been named as the winning proposal in the competition for the integral remodelling of Madrid-Chamartín Clara Campoamor and its urban integration.

Madrid-Chamartín: Clara Campoamor Station proposal
image : Play-Time

The proposal was nominated by a 16-member jury. Other shortlisted teams included BIG, Foster + Partners, OMA, Zaha Hadid Architects, Grimshaw, RSHP and Souto de Moura.

Ben van Berkel: “We are truly delighted that our design has been nominated as the winning proposal for this extremely exciting urban regeneration project. Madrid is fast becoming one of the most exciting and attractive cities in Europe. The transformation of this area will invigorate this part of the city while adding new green lungs to Madrid. We are thrilled to have worked with the best possible local partners on this proposal, as collaboration was key to our team’s success.”

Madrid-Chamartín: Clara Campoamor Station proposal
image : Play-Time

The international competition was launched in 2020 by Adif Alta Velocidad (AV) to transform the Madrid-Chamartín Clara Campoamor railway hub into an international benchmark for sustainable, multimodal, connected and integrated mobility.

UNStudio, b720 Arquitectura and Esteyco’s proposal, christened ‘Open ecosystem’, unanimously obtained the maximum possible score from the jury, which considered aspects such as functionality – railway, commercial and tertiary – constructive feasibility, accessibility and integration into the city, environmental sustainability and inclusivity, with the aim of turning the Chamartín complex into an urban and architectural reference in Madrid.

Madrid-Chamartín: Clara Campoamor Station proposal
image : Play-Time

A key element that the team deemed essential in the proposed design was to retain and respect the historical vaulted roofs of Chamartín station, recognising them as a singular and identifying element of the station. Stepped terraces are then added to generate permeability with the surrounding city, while urban balconies open views over the station and integrate the complex into its surroundings. The station therefore forms a porous extension to the new parks located on either side of the complex.

Ben van Berkel: “Our main focus was to retain and improve the existing station complex and to activate its surroundings with a careful mix of fast and slow programme; to design a highly sustainable future-proof urban hub, while densifying and truly activating the area with working, living, leisure and learning. The new station area will vastly improve this part of the city, attracting new flows of people and bringing quality of life in this part of Madrid to the next level.”

Madrid-Chamartín: Clara Campoamor Station proposal
image : Play-Time

Flanked by new towers and fronted by a public square, the proposed new station hosts a wide array of commercial programmes. In the design, the complex is transformed into a large urban courtyard that serves as a fully integrated mobility hub that provides easy access to other modes of transport, such as taxi, metro and active mobility (pedestrians, bicycles, scooters).

The integrated sustainability strategy responds to the criterion of an adaptable and inclusive infrastructure: accessible, digitised, last mile logistics and urban design, designed for pedestrians and local mobility; doubling capacity and organising flows.

Madrid-Chamartín: Clara Campoamor Station building design
image : b720

The design for the Madrid-Chamartín Clara Campoamor masterplan builds on UNStudio’s 30 years of experience and accumulated expertise in station design. From Arnhem Central Station to the Doha Metro Network, UNStudio has consistently put design excellence, urban activation, sustainability and outstanding user experience at the forefront of its mobility projects.

Madrid-Chamartín: Clara Campoamor Station building
image : bucharest.studio

Madrid-Chamartín: Clara Campoamor Station – Building Information

UNStudio Team: UNStudio: Ben van Berkel and Astrid Piber with Enrique López, Lars van Hoften, Christian Robles, Nikoleta Mougkasi, Alba Peláez, Khaled Omara, Dichao Wang, Qiliang Tang, Craig Trompetter.
With advice from: Arjan Dingsté, Ren Yee, Jaap-Willem Kleijwegt.

Visualisations by: bucharest.studio, Play-Time, b720
